MODEL

DESCRIPTION

EPG428-1

Electrical Pattern Generator 4 channel 2 - 28.4 Gbps, 200 – 800 mV

EED428-1

Electrical Error Detector 4 channel 25.6 - 28.4 Gbps, 200 – 1200 mV SE input

EPG10-6

Electrical Pattern Generator 2 - 14.4 Gbps, 300 – 1000 mV

EED10-6

Electrical Error Detector 2 - 14.4 Gbps

Electrical Error Detector

The broadband error detector module plugs into the XBERT and ParalleX™ Chassis. The electrical ED generates electrical data streams from 2.0 Gb/s up to 14.4 Gb/s. All PRBS patterns are supported as well as user patterns. Operation is done via GUI on computer. Front panel indicators give immediate status for Tx data.

Characteristics

Key Features and Benefits

Data Rates 2 Gb/s to 13 Gb/s, optionally 14.4Gb/s
Single ended input, optionally differential
PRBS7, PRBS9, PRBS10, PRBS11, PRBS15, PRBS21,
PRBS23, PRBS31, CJPATT, SSPS-64, 0101, 1100,
K28.5, K28,7, 48A.1, 48A.2, 48A.3
64Kbit user defined (Optional PRBS20, PRBS28)
Variable sampling point
Automatic alignment
Clock output

Applications

Protocol independent Test of
Fibre Channel: 2GFC, 4GFC, 8GFC, 10GFC, 16GFC
SONET: OC-48, OC-192
SDH: STM-16, STM-64
Infiniband: SDR, DDR, QDR, FDR
Ethernet , 10 GbE, 40Gbase, 100Gbase
CEI, SFP+, XFP/XFI
Traffic generator
Components verification
Serial BUS and Backplane Test

Quick Links

Product Brief - Electrical Error Detector 10-6
Options:
Option 146 Vertical sample point adjustment for EED10-6
Option 147 Differential inputs
Option 153 Data rate extension to 1.0 Gbps for EED10-6

EBERT-3

Electrical BERT 9.9 - 11.3 Gbps with Pre-Emphasis option

Electrical BERT

Our electrical BERT is a 10G BERT Module that plugs in to the XBERT and ParalleX™ Chassis. The BERT Module can generate and receive electrical data from 9.9 Gb/s up to 11.3 Gb/s. Optionally the BERT module can operate at 4.9 Gb/s up to 5.7 Gb/s. PRBS and user programmable patterns can be changed via an easy to use GUI. A pattern trigger output provides an electrical trigger synchronous with the B ERT pattern for use with an oscilloscope or other test equipment. Optional Pre-emphasis (option 118) applies frequency selective attenuation to the data signal at the transmit side of the BERT to compensate for losses in the transmit medium. Front panel indicators give immediate status for Tx and Rx Data.

Characteristics

Data Rates 9.9 to 11.3 Gb/s. Optional 4.9 to 5.7 Gb/s
PRBS7, PRBS9, PRBS10, PRBS11, PRBS15, PRBS21, PRBS23, PRBS31
CJPATT, SSPS-64, 0101, 1100, K28.5, K28,7,
48A.1, 48A.2, 48A.3 and 64Kbit user defined (Optional PRBS20, PRBS28)
10GHz Clock Output (single ended)
Single error and error rate injection: E-3 to E-15
BER Test Error Detection: 0.5 to < 10E-15
Gating-time: up to 5000h
Pre-emphasis of Transmit signal for distance EQ
Ideal BER Tester For Production Line, up to 7 BERTs in 19" housing
Subrated clock output

Applications

Protocol independent 10G BER Test of OC192, Fibrechannel,
FB-DIMM, Infiniband, 10 GbE, 40Gbase, 100Gbase, CEI, SFP+, XFP/XFI
Signal generator
Components verification
Serial BUS and Backplane Test
FEC Test

Quick Links

Product Brief - EBERT-3
Options:
Option 108 Pre-Emphasis output for EBERT-3

EPG10-3

Electrical Pattern Generator 8.5 - 11.3 Gbps

EBERT-5

Electrical BERT 8.5 G - 11.3 Gbps, adjustable crossing, variable data output level

Electrical BERT

Our 10G Serial BERT is a Bit Error Rate Test module that plugs in to the XBERT and ParalleX™ Chassis. Electrical BER Tester can generate and receive electrical data from 8.5 Gb/s (option: 8.0Gb/s) up to 11.3 Gb/s. User programmable PRBS patterns can be changed via an easy to use GUI. A pattern trigger output provides an electrical trigger synchronous with the pattern for use with an oscilloscope or other test equipment. Front panel indicators give immediate status for Tx and Rx Data.

Characteristics

Data Rates 8.5Gb/s (option: 8.0) to 11.3 Gb/s.
PRBS7, PRBS9, PRBS10, PRBS11, PRBS15, PRBS21, PRBS23, PRBS31
CJPATT, SSPS-64, 0101, 1100, K28.5, K28,7,
48A.1, 48A.2, 48A.3 and 64Kbit user defined (Optional PRBS20, PRBS28)
Adjustable TX Amplitude
Output crossing adjustable from 20% to 80%
Single error and error rate injection: E-3 to E-15
BER detection: 0.5 to < 10E-15
Gating-time: up to 5000h
High sensivity
Pattern Trigger output
Subrated clock output

Applications

Protocol independent BER Tester of OC-192, Fibrechannel, FB-DIMM,
Infiniband, 10 GbE, 40Gbase, 100Gbase, CEI, SFP+, XFP/XFI
Traffic generator
Components verification
Serial BUS and Backplane Test

Quick Links

Product Brief - EBERT-5
Options:
Option 112 8.0 Gb/s as lowest data rate for EBERT-5 (8 – 11.3 Gb/s)

EPG10-5

Electrical Pattern Generator 8.5 - 11.3 Gbps

Pattern generator

EPG10-5 is an Electrical Pattern Generator module that plugs into the XBERT and ParalleX™ Chassis. EPG10-5 can generate electrical data from 8.5 Gb/s (option: 8.0Gb/s) up to 11.3 Gb/s. Optionally the EPG10-5 module can operate at 4.3 Gb/s (option: 4.0Gb/s) up to 5.7 Gb/s. User programmable PRBS patterns can be changed via an easy to use GUI. A pattern trigger output provides an electrical trigger synchronous with the pattern for use with an oscilloscope or other test equipment. Front panel indicators give immediate status for Tx Data.

Characteristics

Data Rates 8.5 Gb/s up to 11.3 Gb/s. Optional 4.3 to 5.7 Gb/s
PRBS7, PRBS9, PRBS10, PRBS11, PRBS15, PRBS21, PRBS23, PRBS31
CJPATT, SSPS-64, 0101, 1100, K28.5, K28,7,
48A.1, 48A.2, 48A.3 and 64Kbit user defined (Optional PRBS20, PRBS28)
10GHz Clock Output (single ended)
Optional Pre-emphasis of Transmit signal for distance EQ
Ideal BER Tester For Production Line, up to 7 BERTs in 19" housing
Subrated clock output

Applications

Protocol independent 10G BER Test of OC192, Fibrechannel,
FB-DIMM, Infiniband, 10 GbE, 40Gbase, 100Gbase, CEI, SFP+, XFP/XFI
Signal generator
Components verification
Serial BUS and Backplane Test
FEC Test
